 3230 no power done

View previous topic View next topic Go down
AuthorMessage
banico_25
Global Administrator
Global Administrator


Join Date : 2010-12-04
Location : Cavite
Male Age : 33
Posts : 1140

PostSubject: 3230 no power done   December 17th 2010, 07:41

3230 no power done









share kolang poh itong 3230 ginawa ko..................

no power poh ..............

hestiry bigla nalang daw poh..................

1rst step;flash sa jaf no luck........

Getting MCU ID

MCU ID: 0x1081
FLASH ID0: 007E0001 <=> SPANSION -> Type not in database Addr0: 0x00000000 - 0x00FFFFFF, SectorSize0: 10
FLASH ID1: 007E0001 <=> SPANSION -> Type not in database Addr1: 0x02000000 - 0x02FFFFFF, SectorSize1: 10
FLASH ID2: 277E0001 <=> SPANSION -> Type not in database Addr2: 0x04000000 - 0x04FFFFFF, SectorSize2: 10
FLASH ID3: 00010000 <=> Flash -> not used Addr3: 0x06000000 - 0x06FFFFFF, SectorSize3: 0
First 16 bytes: C6 00 00 EA 75 01 00 EA 78 01 00 EA 7B 01 00 EA
Checking RAM for ALGO...
Algo is ready...
Checking FAID calculation...
P-key nokia module version 01.02
Done!
Phone Restarted...
Phone Type:
FILES SET FOR FLASHING:
MCU Flash file: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.C1
PPM Flash file: NONE
CNT Flash file: NONE
ADSP Flash file: NONE
APE Variant file: NONE
APE User Flash file: NONE
Phone Type:
FILES SET FOR FLASHING:
MCU Flash file: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.C1
PPM Flash file: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.26
CNT Flash file: NONE
ADSP Flash file: NONE
APE Variant file: NONE
APE User Flash file: NONE
Backing up PM Field 208 as RPL...
Setting local mode...
Failed! Aborting!
Failed to backup imei...
MCU: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.C1
Booting phone...
MCU ID: 0x1081
BOOT file: C:\Program Files\ODEON\JAF\Flash\w3_2nd.fia
Loader version: 04.46.01 -> Revision: 0007
Boot size is 0x10D8
Boot is ready...
FLASH ID0: 007E0001 <=> SPANSION -> Type not in database Addr0: 0x00000000 - 0x00FFFFFF, SectorSize0: 10
FLASH ID1: 007E0001 <=> SPANSION -> Type not in database Addr1: 0x02000000 - 0x02FFFFFF, SectorSize1: 10
FLASH ID2: 277E0001 <=> SPANSION -> Type not in database Addr2: 0x04000000 - 0x04FFFFFF, SectorSize2: 10
FLASH ID3: 00010000 <=> Flash -> not used Addr3: 0x06000000 - 0x06FFFFFF, SectorSize3: 0
First 16 bytes: C6 00 00 EA 75 01 00 EA 78 01 00 EA 7B 01 00 EA
Flash ID is 0x007E0001
Flash loader is C:\Program Files\ODEON\JAF\Flash\w3_amd.fia
Loader version: 04.46.01 -> Revision: 0007
Loader size is 0x7F10; Loader chk: c3
Loader is ready...
P-key nokia module version 01.02
MSID: 84CF808371CB64356BC6066555
MSID decoded: 3E4EBAF700453F0EA8000000
FAID: 8A6A89351D9C5E43500AD2F2
Operation took 0 minutes 20 seconds...
Erasing...
Found 4 interval(s) to erase
Erasing area: 00000000 - 0000FFFF...
Erasing area: 00010000 - 00FFFFFF...
Erasing area: 02000000 - 02A9FFFF...
Erasing area: 02FC0000 - 02FEFFFF...
Operation took 3 minutes 19 seconds...
Writing...
Perm. Data Restore OK
Operation took 3 minutes 19 seconds...
Restarting MCU...
PPM: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.26
Booting phone...
MCU ID: 0x1081
BOOT file: C:\Program Files\ODEON\JAF\Flash\w3_2nd.fia
Loader version: 04.46.01 -> Revision: 0007
Boot size is 0x10D8
Boot is ready...
FLASH ID0: 007E0001 <=> SPANSION -> Type not in database Addr0: 0x00000000 - 0x00FFFFFF, SectorSize0: 10
FLASH ID1: 007E0001 <=> SPANSION -> Type not in database Addr1: 0x02000000 - 0x02FFFFFF, SectorSize1: 10
FLASH ID2: 277E0001 <=> SPANSION -> Type not in database Addr2: 0x04000000 - 0x04FFFFFF, SectorSize2: 10
FLASH ID3: 00010000 <=> Flash -> not used Addr3: 0x06000000 - 0x06FFFFFF, SectorSize3: 0
First 16 bytes: C6 00 00 EA 75 01 00 EA 78 01 00 EA 7B 01 00 EA
Flash ID is 0x007E0001
Flash loader is C:\Program Files\ODEON\JAF\Flash\w3_amd.fia
Loader version: 04.46.01 -> Revision: 0007
Loader size is 0x7F10; Loader chk: c3
Loader is ready...
P-key nokia module version 01.02
MSID: 84CF808371CB64356BC6066555
MSID decoded: 3E4EBAF700453F0EA8000000
FAID: 8A6A89351D9C5E43500AD2F2
Operation took 0 minutes 20 seconds...
Erasing PPM...
Found 3 interval(s) to erase
Erasing area: 00000000 - 0000FFFF...
Erasing area: 02B00000 - 02EFFFFF...
Erasing area: 04600000 - 0474FFFF...
Operation took 0 minutes 39 seconds...
Writing...
Perm. Data Restore OK
Operation took 0 minutes 39 seconds...
Restarting MCU...
Flashing Done!
Operation took 9 minutes 8 seconds...

After flash processing...
Waiting for phone to boot...
Failed! Aborting!


ayaw poh mag boot ang phone high and low vertion......

2nd step;flash sa HWK no luck.....
[IMG]



3rd step;flash sa UB no luck parin..........
[IMG]



ayaw poh mag boot ang phone kaya nasa f12 ang problima hindi makuha SW sa 3 box kaya HW na talaga ako.........
2 poh flash ic nya yong malaki F10/F11 yong maliit naman ay F12 kaya F12
lang inalog ko yong maliit done poh sya wala nang ibang pyisang na
damay swak kaagad..............

sa kanan ng UPP yong maliit sa taas yon ang F12
[IMG]



flash ko sa jaf tuloy-tuloy na poh sya wala ng failed
Getting MCU ID

MCU ID: 0x1081
FLASH ID0: 007E0001 <=> SPANSION -> Type not in database Addr0: 0x00000000 - 0x00FFFFFF, SectorSize0: 10
FLASH ID1: 007E0001 <=> SPANSION -> Type not in database Addr1: 0x02000000 - 0x02FFFFFF, SectorSize1: 10
FLASH ID2: 277E0001 <=> SPANSION -> Type not in database Addr2: 0x04000000 - 0x04FFFFFF, SectorSize2: 10
FLASH ID3: 00010000 <=> Flash -> not used Addr3: 0x06000000 - 0x06FFFFFF, SectorSize3: 0
First 16 bytes: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
Checking RAM for ALGO...
Algo is ready...
Checking FAID calculation...
P-key nokia module version 01.02
Done!
Phone Restarted...
Backing up PM Field 208 as RPL...
Setting local mode...
Failed! Aborting!
Failed to backup imei...
MCU: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.C1
Booting phone...
MCU ID: 0x1081
BOOT file: C:\Program Files\ODEON\JAF\Flash\w3_2nd.fia
Loader version: 04.46.01 -> Revision: 0007
Boot size is 0x10D8
Boot is ready...
FLASH ID0: 007E0001 <=> SPANSION -> Type not in database Addr0: 0x00000000 - 0x00FFFFFF, SectorSize0: 10
FLASH ID1: 007E0001 <=> SPANSION -> Type not in database Addr1: 0x02000000 - 0x02FFFFFF, SectorSize1: 10
FLASH ID2: 277E0001 <=> SPANSION -> Type not in database Addr2: 0x04000000 - 0x04FFFFFF, SectorSize2: 10
FLASH ID3: 00010000 <=> Flash -> not used Addr3: 0x06000000 - 0x06FFFFFF, SectorSize3: 0
First 16 bytes: FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
Flash ID is 0x007E0001
Flash loader is C:\Program Files\ODEON\JAF\Flash\w3_amd.fia
Loader version: 04.46.01 -> Revision: 0007
Loader size is 0x7F10; Loader chk: c3
Loader is ready...
P-key nokia module version 01.02
MSID: 84CF808371CB64356BC6066555
MSID decoded: 3E4EBAF700453F0EA8000000
FAID: 8A6A89351D9C5E43500AD2F2
Operation took 0 minutes 19 seconds...
Erasing...
Found 4 interval(s) to erase
Erasing area: 00000000 - 0000FFFF...
Erasing area: 00010000 - 00FFFFFF...
Erasing area: 02000000 - 02A9FFFF...
Erasing area: 02FC0000 - 02FEFFFF...
Operation took 3 minutes 20 seconds...
Writing...
Perm. Data Restore OK
Operation took 3 minutes 20 seconds...
Restarting MCU...
PPM: C:\Program Files\Nokia\Phoenix\Products\rm_51\RM51PE507170.26
Booting phone...
MCU ID: 0x1081
BOOT file: C:\Program Files\ODEON\JAF\Flash\w3_2nd.fia
Loader version: 04.46.01 -> Revision: 0007
Boot size is 0x10D8
Boot is ready...
FLASH ID0: 007E0001 <=> SPANSION -> Type not in database Addr0: 0x00000000 - 0x00FFFFFF, SectorSize0: 10
FLASH ID1: 007E0001 <=> SPANSION -> Type not in database Addr1: 0x02000000 - 0x02FFFFFF, SectorSize1: 10
FLASH ID2: 277E0001 <=> SPANSION -> Type not in database Addr2: 0x04000000 - 0x04FFFFFF, SectorSize2: 10
FLASH ID3: 00010000 <=> Flash -> not used Addr3: 0x06000000 - 0x06FFFFFF, SectorSize3: 0
First 16 bytes: C6 00 00 EA 75 01 00 EA 78 01 00 EA 7B 01 00 EA
Flash ID is 0x007E0001
Flash loader is C:\Program Files\ODEON\JAF\Flash\w3_amd.fia
Loader version: 04.46.01 -> Revision: 0007
Loader size is 0x7F10; Loader chk: c3
Loader is ready...
P-key nokia module version 01.02
MSID: 84CF808371CB64356BC6066555
MSID decoded: 3E4EBAF700453F0EA8000000
FAID: 8A6A89351D9C5E43500AD2F2
Operation took 0 minutes 20 seconds...
Erasing PPM...
Found 3 interval(s) to erase
Erasing area: 00000000 - 0000FFFF...
Erasing area: 02B00000 - 02EFFFFF...
Erasing area: 04600000 - 0474FFFF...
Operation took 0 minutes 40 seconds...
Writing...
Perm. Data Restore OK
Operation took 0 minutes 40 seconds...
Restarting MCU...
Flashing Done!
Operation took 9 minutes 12 seconds...

After flash processing...
Waiting for phone to boot...
Reading...
Phone type: RM-51, Software version: 5.0717.0
IMEI: 357099002887025
Product Code: 0522380
Resetting PPC...
Done!
Powering the phone...
Unlocking...
IMEI: 357099002887025
ASIC: 5
SW version: 5.0717.0
Checking locks...

Block 1:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 2:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 3:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 4:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 5:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 6:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 7:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN

Done!
DCT4 unlock counter: 264


sabi ng iba dito sa post ko UPP na daw nako poh mahirap galawin yon baka tuloyang mamahinga ang unit....

flash ic lang talaga pag ganito mga sintumas ng 3230 no power tested by
jesse_25

taos puso din poh akong nag papasalamat sa lahat ng nag reply sa post ko may na pulot din poh akong idia..........

http://gsmsandwich.com.ph/forum/showthread.php?t=209190

[IMG]

[IMG]



















__________________
Back to top Go down
Guest
Guest



PostSubject: Re: 3230 no power done   December 19th 2010, 07:08

paki bilogan naman ang F12 boss kung saan...
Back to top Go down
syrose



Join Date : 2011-10-31
Posts : 13

PostSubject: Re: 3230 no power done   November 10th 2011, 04:55

astig galing mo
Back to top Go down
RENALD
Super Moderator
Super Moderator


Join Date : 2012-03-06
Location : ANTISEC.PHILIPINES
Male Age : 25
Posts : 233

PostSubject: Re: 3230 no power done   June 13th 2012, 09:33

lupet nun ah?? Very Happy
Back to top Go down
celmate



Join Date : 2012-06-18
Location : marikina city
Male Posts : 4

PostSubject: Re: 3230 no power done   June 20th 2012, 04:21

paki bilugan naman sir yung component IC...thanks:D
