 5130c whitescreen hang done via mxkey hti

View previous topic View next topic Go down
AuthorMessage
rafskie
Moderator
Moderator


Join Date : 2012-10-15
Location : lipa city
Male Age : 33
Posts : 163

PostSubject: 5130c whitescreen hang done via mxkey hti   November 27th 2012, 03:47

share ko lng mga boss..

basi sabi ng costomer. nag ttxt lang daw sya mga boss.
tas bgla nlang daw nagwhite screen..
kaya flash ko sya agad hti.

ito ang logs..



MXKEY [MxKey Team HTI PLUS Flasher Interface 3], SN: C0872EAB
Using device: USB ROM and HTI, FW ver: 00.50, SN: 01008F7B
Connection status: EHCI:HUB:HUB::USB 2.00 (Full-speed)
Driver: NMWCD, ver: 7.1.32.75
Module ver: 1.0.0.21151(13-07-2012), Library ver: 1.0.0.14195(13-07-2012)
Processing MCU file: rm495__07.97.mcusw
[BB5,BB5 ALGORITHM] size: 18.20 MB
Supported Ids: 010C192101013000, 0103192101003000, 0303192101033000, 030C192101033000
Make sure USB cable, Battery and charger are removed from device.
Insert USB cable, Battery back to device(make sure to have fully charged battery).
Insert Charger or Press phone's power button(if flashing doesnt start automatically)
Waiting for USB ROM device ...
CMT SYSTEM ASIC ID: 000000010000022600010006030C192101033000 [RAP3G ver: PA 3.0]
CMT EM0 ID: 00000296
CMT EM1 ID: 00000B22
CMT PUBLIC ID: 0790000C0E9D7D56F2399EEA5F9B44FADBAA7A55
CMT ASIC MODE ID: 00
CMT ROOT KEY HASH: 9DDBFCFE6E73CED7D8C6268C8EB85723
CMT ROM ID: 273F6D55DFAAF68F
Flashing CMT Update Server Data, ULO: 0x3900 bytes
Update Server code succesfully sent to phone.
Flashing CMT Update Server Data, UPDAPP: 0x4B340 bytes
Update Server code succesfully sent to phone.
Flashing CMT Update Server Data, PASUBTOC: 0x59940 bytes
Update Server code succesfully sent to phone.
Waiting for USB device removal ...
Device connected: nmwcdnsuc\Nokia BB5 ADL Loader USB Generic, PORT_ID: 15CC7D91
Verifying communication to device OK.
Erase size: 21 MB
CMT FLASH,NOR area [00000000-000006BF] erased in 0.625 s
CMT FLASH,NOR area [000006C0-0001FFFF] erased in 0.672 s
CMT FLASH,NOR area [00040000-000BFFFF] erased in 2.312 s
CMT FLASH,NOR area [000C0000-0013FFFF] erased in 2.204 s
CMT FLASH,NOR area [00140000-0137FFFF] erased in 1 min 19.062 s
CMT FLASH,NOR area [01380000-0151FFFF] erased in 7.094 s
Flash programming ...
CMT NOLO block sent
CMT KEYS block sent
CMT PRIMAPP block sent
CMT PASUBTOC block sent
Selecting first CMT PAPUB block with matching RootKey.
CMT PAPUBKEYS: 0C917F11 [RAP Certificate 164 v.1] sent
CMT UPDAPP block sent
CMT DSP0 block sent
CMT MCUSW block sent
Programming completed in 1 min 0.828 s
Processing PPM file: rm495__07.97.ppm_x
[BB5,BB5 ALGORITHM] size: 7.72 MB
Supported Ids: 010C192101013000, 0103192101003000, 0303192101033000, 030C192101033000
Erase size: 8.62 MB
CMT FLASH,NOR area [01520000-01DBFFFF] erased in 36.875 s
Flash programming ...
Programming completed in 28.359 s
Processing CNT file: rm495__07.97.image_x_blu
[BB5,BB5 ALGORITHM] page size: 128 K size: 13.02 MB
Supported Ids: 010C192101013000, 0103192101003000, 0303192101033000, 030C192101033000
Erase size: 34 MB
CMT FLASH,NOR area [01DC0000-0215FFFF] erased in 25.047 s
CMT FLASH,NOR area [02160000-03FBFFFF] erased in 3 min 21.969 s
Flash programming ...
Programming completed in 43.703 s
Total time for flashing process(boot+erase+write) was 8 min 49.891 s
Waiting for USB device removal ...OK
Waiting for USB device arrival ...
Waiting for device boot up ...
Device connected: nmwcdc\Nokia 5130 XPressMusic USB Phonet, PORT_ID: 72DA3C
Verifying communication to device OK.



Phone type: RM-495 (Nokia 5130c-2)
SW version: V 07.97 13-09-10 RM-495 (c) Nokia
Imei plain: 35417903521150-1
Product code: 0571943
Battery voltage: 3151 mV, current: 74 mA
Language Pack:
- not available.

SLPA ver[4]: PA_SL3/PA_SIMLOC30 (15 digit NCK)
warning: avoid SW Downgrade & manual erase to this phone !
Camera config: NIMMIIIIRRFF0A021001, ver: 002.007

SIMLOCK seems to be valid
SUPERDONGLE_KEY seems to be valid
CMLA_KEY seems to be valid
WMDRM_PD seems to be valid
SIMLOCK_TEST passed
SECURITY_TEST passed


Imei net: 354179035211501
Version: SIMLOCK SERVER
Counter: 0/3, 0/10

CONFIG_DATA: 2440700000000000
PROFILE_BITS: 0000000000000000

BLOCK1: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
BLOCK2: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
BLOCK3: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
BLOCK4: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
BLOCK5: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
BLOCK6: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
BLOCK7: 1=OPEN, 2=OPEN, 3=OPEN, 4=OPEN, 5=OPEN
FULL FACTORY... OK







yan po mga boss finish product cheers
Back to top Go down
meynard
Senior V.I.P
Senior V.I.P


Join Date : 2012-10-18
Location : batangas city
Posts : 24

PostSubject: Re: 5130c whitescreen hang done via mxkey hti   November 27th 2012, 03:53

congratz boss..

nice share good job...


thanks
Back to top Go down
rick22g
Moderator
Moderator


Join Date : 2011-01-17
Location : Siargao Island Surigao del Norte
Male Age : 38
Cell Phone # : 09068621042 / 09284021748
Posts : 73

PostSubject: Re: 5130c whitescreen hang done via mxkey hti   November 27th 2012, 04:12

galing good idea boss,
Back to top Go down
